This Solar Panel is no longer unavailable
High Output and Efficiency
The LG NeON® R series has been designed for high-power output making it efficient even in limited space.
25-Year Warranty
The NeON® R series offers a 25-year limited warranty for performance, product and labor. At 25 years, the modules are guaranteed to produce at least 92.5% of their labeled power output.
Roof Aesthetics
The LG NeON® R series has been designed with aesthetics in mind; with no electrodes on the front, the modules have a sleek, modern appearance.
Excellent Performance on Hot Day
The LG NeON® R series performs well on hot
days due to a low temperature coefficient.
GENERAL DATA
- Cell Properties (Material/Type): Monocrystalline/N-type
- Cell Configuration: 66 Cells (6 x 11)
- Module Dimensions (L x W x H): 75.2"x41"x1.58"
ELECTRICAL PROPERTIES (STC*)
Maximum Power (Pmax) [W]: 440
MPP Voltage (Vmpp) [V]: 41.4
MPP Current (Impp) [A]:10.64
Open Circuit Voltage (Voc, 5%) [V]: 48.2
Short Circuit Current (Isc, 5%) [A]: 11.20
Module Efficiency [%]: 22.1
Power Tolerance [%]: 0 ~ +3
LG440 SPEC SHEET
