AERL RACEMAX MAXIMIZER MPPT Solar Car Controller 600B
Discontinued
CCA11400
This product has been discontinued. We do not expect it to become available again.
Contact us to find a replacement.
This Product has been discontinued
The AERL RACEMAX 600B is a high current, high efficiency, boost-only race-trim maximum power point tracker. It employs a tracking strategy which regulates the PV array voltage to a fixed percentage of its open circuit voltage. This tracking strategy has been proven to be highly robust, immune to local extrema, and results in power losses of less than 0.5% over the whole operating temperature range of a PV array.
The RACEMAX 600B is an ideal choice for solar car teams looking to get the most out of their PV array,
AERL RACEMAX 600B Features:
- High 98-99% operating eficiency
- Compatible with all types of solar cells and battery arrays
- Passive cooling & no moving parts results in highly reliable operation to 50°C
- Output voltage options of 72, 96, 120, 144V
- Compact and lightweight design, weighing only 750g
- Charges higher voltage battery packs from lower voltage solar arrays
Specifications
| Model Number | RACEMAX 600B |
| Maximum ambient air temperature | 50°C |
| Efficiency @ 6A, 100Vmp, & 25Camb |
98.00% |
| PV panel short circuit current - constant |
6A |
| PV panel short circuit current – transient |
8A |
| Solar panel peak power | 600W |
| PV panel open circuit voltage | 40 to 135V |
| Battery Voltage (Selectable) | 72V, 96V, 120V, and 144V |
| Weight | 1.59 lbs (720g) |
| Dimension (L x W x H) | 6.69" x 4.72" x 2.56" (170 x 120 x 65 mm) |
| More detailed information: | |
 |
|
|
AERL RACEMAX 600B Manual.pdf |
