CruzPro TL60 Digital Tank Level Gauge For 3 Tanks

CruzPro TL60 Digital Tank Level Gauge clever very accurate, provides an accurate digital display for three tanks.

Model#

TL-60R Round

TL-60S Square

TL60 Digital Tank Level Gauge Specifications:

Operating Voltage:

• 9.5 - 33.0 VDC

Current Drain:

• 0.018 amps nominal

Data:

• Tank Level Display for Three Tanks

External Outputs/Alarms:

• The NMEA 0183 data output terminal may be programmed as an external alarm output

Inputs:

• Tank Level Senders: All popular American and/or European senders. Senders may be mixed (self-learning), such as GM, VDO, Teleflex, Faria, Centroid, Aerotech, Stewart-Warner, etc. The TL60 is manufactured to work with any standard resistance type level sender having the following resistance ranges: 0-30, 0-70, 0-90, 10-73, 10-180, 33-240, 40-250 ohms (and their reverse 30-0, 70-0, 90-0, 73-10, 180-10, 240-33, 250-40 ohms). The TL60 will actually also work with any non-standard resistive sender that varies from a minimum of 0 ohms to a maximum of 300 ohms or a maximum of 300 ohms to a minimum of 0 ohms. For example, a resistive sender that varies in resistance from 100 to 150 ohms would work. So would a sender that varies from 75 ohms to 25 ohms. The TL60 can also be ordered from the factory set to work with 4-20mA senders or 0-5V sender, as a special order item.

Display:

• 4 digit LCD, 5 levels of backlighting

Data Output:

• NMEA 0183 serial 4800 BAUD for each tank separately ($IIXDR sentence).

Alarms:

• Built-in 85 dB audible alarm. Independent settable low and high level alarms.

Fuel Transfer Pump Control:

• Programmable lower fuel level limit to turn ON a fuel transfer pump.
• Programmable upper fuel level limit to turn OFF the fuel transfer pump.

External Alarm Output:

• Built-in 85 dB audible alarm. Independent settable low and high level alarms for each tank.

Size:

• 2.5" dia X 4.1" deep (61mm x 104mm)

Mounting:

• 2-1/8" (55mm) round hole

CruzPro TL-60 Connection Diagram

CruzPro TL-60 Information:
	CruzPro TL60 Manual
