Hypertech Galvanic Isolator Plus

  • Hypertech Galvanic Isolator Plus
$255.00
$255.00 $264.71
SKU: GIY12110

Questions about compatibility? Call us for help.

Get an additional off

Add the item to cart to apply the discount

Ships in 1-2 business days

Carrier delivery times and cost shown at checkout.

This item is currently out of stock. We can often special-order it or suggest an equivalent.

Request a quote or availability or call 954-581-2505.

Sorry, it's out of stock.

But we can let you know when it's back in.

The Hypertech Galvanic Isolator Plus provides about 2.5 volts of isolation in the ground lead of your shore power, for aluminum hulls and other metal boats. It is for owners on 30A or 50A shore power who want to protect against stray dock voltage, because standard isolators lose protection on aluminum.

Hypertech Galvanic Isolator Plus Hookup Diagram

Aluminum hulls have a built-in electric potential of -0.75 to -1.0-Volts, depending on the alloy, temperature, salinity, and movement. Conventional Galvanic Isolators provide about 1 to 2-Volts of isolation, so protection is degraded by up to 80% to negative stray voltages when applied to aluminum hulls.

  • Works on 115- or 230-Volt supply, single or 2-phase
  • Fail-safe, meets ABYC standards (except 2.5V rating exceeds specifications)
  • Compact size: 8” x 3” x 1.5”

Specifications

  • Isolation: approximately 2.5 volts
  • AC continuous rating: 50 amps
  • Shore power: any connection up to 50 amps; only one needed for dual 30-amp connections
  • Leads: two 18 in, 10-gauge marine grade
  • Housing: non-metallic with mounting tabs, waterproof
  • Ignition protected
  • Operating temperature: up to 122 °F (50 °C)
  • Mounting and connection hardware included
  • Warranty: 1-year limited, factory direct

Questions & Answers

Where is the isolator installed?

Inside the boat, in the ground wire between the shore power connector and the vessel ground, preferably within about 15 inches of the shore power entry.

Do I need two for dual 30-amp cords?

No. Only one is required for dual 30-amp connections. Connect the two ground terminals together before passing through the isolator.

How often should it be tested?

The manual says to test it once per season, and again after a nearby lightning strike or an on-board electrical short.
