OutBack Power EnergyCell 220GH Front Terminal 12V
Regular price
$620.00
Sale price
$620.00
Regular price
$0.00
Unit price
per
BDO20220
Questions about compatibility? Call us for help.
Ships in 5-7 business days
This item ships directly from supplier. Carrier delivery times and cost shown at checkout.
Couldn't load pickup availability
The OutBack Power EnergyCell 220GH Valve Regulated Lead Acid (VRLA) battery is designed for Grid/Hybrid storage applications. EnerSys SBS EON technology incorporates TPPL AGM (Thin Plate Pure Lead Advanced Glass Mat) which allows for greater shelf life, extended float service life in optimal operating conditions, and higher energy density. The EnergyCell GH also features front terminal access with threaded copper inserts providing low maintenance and increased safety.
EnergyCell 220GH Features
- EnerSys SBS EON Technology for Higher Energy Density
- Front Terminal Access for Ease of Installation and Maintenance
- UL-Recognized Component
- Designed for Grid/Hybrid and AC-Coupled Renewable Energy Storage Applications
- Up to 4-Year Full Replacement Warranty
- 18-month shelf life at 77˚F(25˚C)
- Wide Operating Temperature Range
EnergyCell 220GH Specifications
| Models | EnergyCell 220GH |
|
Cells Per Unit |
6 |
| Voltage | 12 VDC |
| Float Charging Voltage | 13.62 VDC / unit average at 77˚F (25˚C) |
| Absorbed Voltage | 14.40 VDC / unit average at 77˚F (25˚C) |
| Maximum Charge Current | 118.8 A |
| Self Discharge | Battery can be stored up to 18 months at 77°F (25°C) before a freshening charge is required. Batteries stored at temperatures greater than 77°F (25°C) will require recharge sooner than batteries stored at lower temperatures |
| Terminal | Threaded copper alloy insert terminal to accept ¼-20 UNC bolt |
| Weight | 132 lbs |
|
Dimensions (H x D x W) |
12.4" x 22.1" x 4.9" |
