QuietTorque 45.0 Electric Drive 45kW 72Vdc

Electric Yacht Offers a complete package designed to make an electric repower as easy and straight forward as possible:

• uses state of the art permanent magnet ac (PMAC) motors and vector motor controllers, maximizing efficiency across the entire operating envelope.
• offers adjustable regeneration that can be optimized to your boat, propeller and sailing conditions.

The QuietTorque™ 45.0 LC is recommended electric propulsion for boats up to 50’ (LOA) and 34,000lbs displacement. The dual power head motor is engineered by Electric Yacht to the specifications of your boat and built and warrantied by Electric Yacht. The systems are liquid cooled providing for high sustained output, ideal for hybrid applications. Typical battery size is 400Ah+ at 72Vdc. These systems can be installed by a competent boat owner, but we do recommend the final commissioning be done with a certified electric technician

The QuietTorqueTM 45.0LC SD is recommended for boats up to 50’ (LOA) and 34,000lbs displacement. Liquid cooling provides for high sustained output, ideal for hybrid applications. Replace diesel engines up to 75hp. Typical battery size is 300 – 600Ah.

Part Numbers:

• QT-45 LC: QT-45.OLC
• QT-45 LC SD: QT45.OLC SD

Note 1: In selecting the correct size electric motor, in areas with strong tides and currents, choose the next larger size motor. If your boat is heavy for its length, size up too. When in doubt, give us a call.

Please note: Due to the way this item ships it is impossible to calculate shipping online.
When ordering this item the shipping added to your total is an estimate only. If you order this item through our web site we will contact you to arrange for the adjustment (if any) to your shipping cost.

Electric Yacht QT-45:
	QT-45 LC Datasheet
	QT-45 Drawing
